Day 15 - Build a Simple Storage Table

http://www.morelikehome.net/2x4s

Can you believe we are halfway through October already?! You can see links to the complete series here, and learn about my Lowe's gift card giveaway here. In this series, we're seeing what we can make out of 2x4s. I want to keep it cheap, keep it easy, and keep it totally doable for anyone. Today we're working on the second half of my favorite project in this series. Yesterday we built a Simple Storage Bin, and today we are going to build the coordinating Simple Storage Table!


This table has a sleek and simple style, and is perfectly sized for tucking a pair of Simple Storage Bins underneath. It would make a great console for the entryway, living room, or even in the bedroom! Ready to get started?



Shopping List:
6  -  2x4s @ 10' long
1  -  2x4  @ 8' long

Tools:
Saw
Drill
2 1/2” screws (or Kreg Jig & 2 1/2" self tapping screws)
4" screws (or Kreg Jig & 2 1/2" self tapping screws)
Wood glue
Wood filler

2x4 Cut List:
(A) - 4  @  28 1/2" (legs)
(B) - 4  @  16"  (sides)
(C) - 4  @  43 1/2"  (front/back)
(D) - 1  @  20"  (support)
(E) - 7  @  48"  (table top)

Dimensions: 48" wide x 30" tall x 24 1/2" deep


Please read all the directions before beginning, and cut your pieces as you go, measuring before each cut. Use 2 1/2” screws or pocket holes with 2 1/2" screws unless otherwise indicated. Always use glue. Pre-drill and countersink your screws. I have not built from these exact plans, so measure lots to make sure things work out!

Step 1: Build the Sides
Use two side boards (B) to connect two legs (A). The top side board should be flush with the top of the legs, the bottom one should be spaces 1" below the top one. Attach these using a Kreg Jig, or by drilling through the legs and into the side boards with 4" screws and glue. Repeat to build the other side section.


Step 2: The Front & Back
Now use the front/back boards (C) to connect the two end sections. In the back, one back boards should be flush with the top of the legs and the other should be spaced one inch below the top one. Attach these using a Kreg Jig, or by drilling through the legs and into the front/back boards with 2 1/2" screws and glue. Repeat to build the front.


Step 3: Support
Attach the support board (D) between the top front and back boards. It should be flush with top edges of the front/back boards and centered with 21" of space on each side. Attach it with your Kreg Jig or by drilling through the front/back boards and into the support board with 2 1/2" screws and glue.


Step 4: The Table Top
Now you can add the table top boards. The top boards should all sit side-by-side centered on the base with 3/4" overhang on all sides. Once your boards are lined up and centered, attach them by drilling down through the table top boards and into the front, back, side, and support boards with 2 1/2" screws and glue.


Step 5: Finishing
Start by filling any holes and sanding everything down nice & smooth. Then just finish with any paint/stain/poly you want! Try pairing a sleek white table with some rustic Storage Bins.


 And be sure to build a few Simple Storage Bins to tuck underneath.


Project 2x4 Cost:
$19.20  -  6   2x4s @ 10' long ($3.20 each)
$2.50  -  1   2x4 @ 8' long ($2.50 each)
$21.70 Total


See giveaway winners here.


Share on Facebook

Day 14 31 Days of 2x4 Projects - Full List Day 16

6 comments:

  1. I often find open bins awkward because they use up valuable "flat space." However, bins with lids are also awkward because you have to clear off all the "junk" on top before you can get in them. This is a great solution to both problems!

    ReplyDelete
  2. I was wondering when we would see the table.

    ReplyDelete
  3. I like the looks of this!

    ReplyDelete
  4. I love the look of the white against that wall color.

    ReplyDelete
  5. Have you actually made this table? Looks like it would be easy although is there a way to attch the top from underneath?

    ReplyDelete
    Replies
    1. I haven't yet. I really want to, but we're stuck waiting for warmer weather! :)
      If you have a Kreg Jig you could use it to attach the top from underneath by making pocket holes in the side boards and support board. Otherwise you could just angle screws through those boards into the top boards underneath where they won't be seen, but you'll have to be careful not to poke through the top. :)
